Carton Break Tester for Cardboard Paper Industry

Carton Break Tester How to test corrugated board ? Carton Breaking Strength Tester is the carton break tester. How to test corrugated paperboard carton rupture strength test chamber is an international universal Mullen instrument. Suitable for packaging materials, mainly used to determine a variety of cardboard and single and multi-layer corrugated cardboard, can also be used for silk, cotton and other non-paper materials, the burst strength test. As long as the material is put in, automatic detection, automatic test, automatic hydraulic pressure return and automatic calculation, storage of test data, printing, instrument digital display and can automatically print test results and data processing .

Bursting strength tester operation steps:
1) After
turning on the power, turn on the power switch and the power indicator light is on;
2) After the
power is turned on for about 30 seconds, the monitor automatically enters the test state, which means 0.00 display, and the monitor no longer beats.
3)
Check whether the thimble of the oil cup is locked. If it is not locked, it must be locked. Check if the air source is leaky. If the air leakage is bad, the air source must be properly adjusted to test; The burst strength tester
4)
Place the prepared sample between the upper and lower platens and prepare to enter the test;
5)
Press Clear to ensure that the display shows 0.00 , then press the Peak button.
6) After
everything is ready, press the motor start button and the cylinder will automatically press down on the test sample. After 5 seconds, the pressure motor will automatically run and pressurize.
7)
When the test strip ruptures, the maximum pressure value is displayed on the display. At this time, the cylinder of the instrument will automatically rise, and the pressure motor will quickly retreat. Be careful not to turn off the power switch.
8)
When the maximum value is retained, press the function key twice to save the maximum value. Press the following keys to print the test value.
9)
Note: If you need to change the unit value of the force value, press the unit conversion key to switch.
10) After the
cylinder returns, remove the test piece. This test is completed.
11)
Test the other group specimens according to the above 4 to 9 items in sequence and record them. The same kind of specimens are averaged.
12)
After the test is completed, turn off the power switch and turn off the power indicator.

Note: General corrugated board should take three points in the positive and negative, and then take the average , product uses: paper and paperboard strength performance testing of the basic equipment, carton rupture strength test chamber for various types of paper and cardboard burst strength test. With simple operation, reliable performance and advanced technology, this instrument is an indispensable ideal equipment for research institutes, paper manufacturers, packaging industry, and quality inspection departments.

Dongguan Haida equipment specializing in the production of carton compression testing machine , burst strength testing machine, drop test bench , vibration testing machine and other packaging testing equipment, welcome to call!

For more detailed product series and related technical parameters, please contact:

National Unified Service Hotline: 400-0711-808

Haida International Instrument: 0769-89280808
